General Purpose Steel Wire Rope

 General Purpose Steel Wire Rope
 General Purpose Steel Wire Rope

Application
Fasten general purpose steel wire rope is highly versatile and can be used for nearly any application, particularly cranes, hoists, and general engineering purposes.

Characteristic
1. Flexible and easy to use, wide range of applications
2. Manufactured as per DIN, as well as customizable options.

Product Structure

  • 6×19-FC
  • 6×19-IWR
  • 7×19
Specifications
Nominal Dia. (mm) Approximate
Weight
Nominal Tensile Strength. Mpa
1570 1670 1770 1870 1960
Min. Breaking Load. KN
D FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
mm kg/100m KN
3.00 3.03 3.43 4.34 4.69 4.61 4.99 4.89 5.29 5.17 5.59 5.41 5.85
4.00 5.39 6.10 7.71 8.34 8.20 8.87 8.69 9.40 9.19 9.93 9.62 10.40
5.00 8.43 9.53 12.00 13.00 12.80 13.90 13.60 14.70 14.40 15.50 15.00 16.20
6.00 12.10 13.70 17.40 18.80 18.50 20.00 19.60 21.20 20.70 22.40 21.60 23.40
7.00 16.50 18.70 23.60 25.50 25.10 27.20 26.60 28.80 28.10 30.40 29.40 31.80
8.00 21.60 24.40 30.80 33.40 32.80 35.50 34.80 37.60 36.70 39.70 38.50 41.60
9.00 27.30 30.90 39.00 42.20 41.50 44.90 44.00 47.60 46.50 50.30 48.70 52.70
10.00 33.70 38.10 48.20 52.10 51.30 55.40 54.30 58.80 57.40 62.10 600.00 65.00
11.00 40.80 46.10 58.30 63.10 62.00 67.10 65.80 71.10 69.50 75.10 72.80 78.70
12.00 48.50 54.90 69.40 75.10 73.80 79.80 78.20 84.60 82.70 89.40 86.60 93.70
13.00 57.00 64.40 81.50 88.10 86.60 93.70 91.80 99.30 97.00 105.00 101.00 110.00
14.00 66.10 74.70 94.50 102.00 100.00 109.00 107.00 115.00 113.00 122.00 118.00 127.00
16.00 86.30 97.50 123.00 133.00 131.00 142.00 139.00 150.00 147.00 159.00 154.00 166.00
18.00 109.00 123.00 156.00 169.00 166.00 180.00 176.00 190.00 186.00 201.00 195.00 210.00
20.00 135.00 152.00 193.00 208.00 205.00 222.00 217.00 235.00 230.00 248.00 240.00 260.00
22.00 163.00 184.00 233.00 252.00 248.00 268.00 263.00 284.00 2787.00 300.00 291.00 315.00
24.00 194.00 219.00 278.00 300.00 295.00 319.00 313.00 338.00 331.00 358.00 346.00 374.00
26.00 228.00 258.00 326.00 352.00 347.00 375.00 367.00 397.00 338.00 420.00 406.00 440.00
28.00 264.00 299.00 378.00 409.00 402.00 435.00 426.00 461.00 450.00 487.00 471.00 510.00
30.00 303.00 343.00 434.00 469.00 461.00 499.00 489.00 529.00 517.00 559.00 541.00 585.00
32.00 345.00 390.00 494.00 534.00 525.00 568.00 556.00 602.00 588.00 636.00 616.00 666.00
34.00 390.00 440.00 557.00 603.00 593.00 641.00 628.00 679.00 664.00 718.00 695.00 752.00
36.00 437.00 494.00 625.00 676.00 664.00 719.00 704.00 762.00 744.00 805.00 780.00 843.00
38.00 487.00 550.00 696.00 753.00 740.00 801.00 785.00 849.00 829.00 896.00 869.00 940.00
40.00 539.00 610.00 771.00 834.00 820.00 887.00 869.00 940.00 919.00 993.00 963.00 1040.00

Product Structure

  • 6×37-FC
  • 6×37-IWR
  • 7×37-IWS
Specifications
Nominal Dia. (mm) Approximate
Weight
Nominal Tensile Strength. Mpa
1570 1670 1770 1870 1960
Min. Breaking Load. KN
D FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
FC
(Fiber Core)
IWR/IWS
(Steel Core)
mm kg/100m KN
6.00 12.10 13.70 16.70 18.00 17.70 19.20 18.80 20.30 19.90 21.50 20.80 22.50
7.00 16.50 18.70 22.70 24.50 24.10 26.10 25.60 27.70 27.00 29.20 28.30 30.60
8.00 21.60 24.40 29.60 32.10 31.50 34.10 33.40 36.10 35.30 38.20 37.00 40.00
9.00 27.30 30.90 37.50 40.60 39.90 43.20 42.30 45.70 44.70 48.30 46.80 50.60
10.00 33.70 38.10 46.30 50.10 49.30 53.30. 52.20 56.50 55.20 59.70 57.80 62.50
11.00 40.80 46.10 56.00 60.60. 59.60 64.50 63.20 68.30 66.70 72.20 69.90 75.60
12.00 48.50 54.90 66.70 72.10 70.90 76.70 75.20 81.30 79.40 85.90 83.20 90.00
13.00 57.00 64.40 78.30 84.60 83.30 90.00 88.20 95.40 93.20 101.00 97.70 105.00
14.00 66.10 74.70 90.80 98.20 96.60 104.00 102.00 111.00 108.00 117.00 113.00 122.00
16.00 86.30 97.50 119.00 128.00 126.00 136.00 134.00 145.00 141.00 153.00 148.00 160.00
18.00 109.00 123.00 150.00 162.00 160.00 173.00 169.00 183.00 179.00 193.00 187.00 202.00
20.00 135.00 152.00 185.00 200.00 197.00 213.00 209.00 226.00 221.00 239.00 231.00 250.00
22.00 163.00 184.00 224.00 242.00 238.00 258.00 253.00 273.00 267.00 289.00 279.00 302.00
24.00 194.00 219.00 267.00 288.00 284.00 307.00 301.00 325.00 318.00 344.00 333.00 360.00
26.00 228.00 258.00 313.00 339.00 333.00 360.00 353.00 382.00 373.00 403.00 390.00 422.00
28.00 264.00 299.00 363.00 393.00 386.00 418.00 409.00 443.00 432.00 468.00 453.00 490.00
30.00 303.00 343.00 417.00 451.00 443.00 479.00 470.00 508.00 496.00 537.00 520.00 562.00
32.00 345.00 390.00 474.00 513.00 504.00 546.00 535.00 578.00 565.00 644.00 592.00 640.00
34.00 390.00 440.00 535.00 579.00 570.00 616.00 604.00 653.00 638.00 690.00 668.00 722.00
36.00 437.00 494.00 600.00 649.00 638.00 690.00 677.00 732.00 715.00 773.00 749.00 810.00
38.00 487.00 550.00 669.00 723.00 711.00 769.00 754.00 815.00 797.00 861.00 834.00 902.00
40.00 539.00 610.00 741.00 801.00 788.00 852.00 835.00 903.00 883.00 954.00 925.00 1000.00
42.00 594.00 672.00 817.00 883.00 869.00 940.00 921.00 996.00 973.00 1050.00 1020.00 1100.00
44.00 652.00 738.00 897.00 970.00 954.00 1030.00 1010.00 1090.00 1070.00 1150.00 1120.00 1210.00
46.00 713.00 806.00 980.00 1060.00 1040.00 1130.00 1100.00 1190.00 1170.00 1260.00 1220.00 1320.00
48.00 776.00 878.00 1070.00 1150.00 1140.00 1230.00 1200.00 1300.00 1270.00 1370.00 1330.00 1440.00
50.00 843.00 953.00 1160.00 1250.00 1230.00 1330.00 1310.00 1410.00 1380.00 1490.00 1450.00 1560.00
52.00 911.00 1030.00 1250.00 1350.00 1330.00 1440.00 1410.00 1530.00 1490.00 1610.00 1560.00 1690.00
54.00 983.00 1110.00 1350.00 1460.00 1440.00 1550.00 1520.00 1650.00 1610.00 1740.00 1690.00 1820.00
56.00 1060.00 1190.00 1450.00 1570.00 1540.00 1670.00 1640.00 1770.00 1730.00 1870.00 1810.00 1960.00
58.00 1130.00 1280.00 1560.00 1680.00 1660.00 1790.00 1760.00 1900.00 1860.00 2010.00 1950.00 2100.00
60.00 1210.00 1370.00 1670.00 1800.00 1770.00 1920.00 1880.00 2030.00 1990.00 2150.00 2080.00 2250.00
62.00 1300.00 1460.00 1780.00 1930.00 1890.00 2050.00 2010.00 2170.00 2120.00 2290.00 2220.00 2400.00
64.00 1380.00 1560.00 1900.00 2050.00 2020.00 2180.00 2140.00 2310.00 2260.00 2440.00 2370.00 2560.00
66.00 1470.00 1660.00 2020.00 2180.00 2150.00 2320.00 2270.00 2460.00 2400.00 2600.00 2520.00 2720.00
68.00 1560.00 1760.00 2140.00 2320.00 2280.00 2460.00 2410.00 2610.00 2550.00 2760.00 2670.00 2890.00
70.00 1650.00 1870.00 2270.00 2450.00 2410.00 2610.00 2560.00 2770.00 2700.00 2920.00 2830.00 3060.00

Product Structure

  • 6×12-7FC
Specifications
Nominal Diam (mm) Approximate Weight (kg/100m) Nominal Tensile Strength (Mpa)
1470 1570 1670 1770
Min.Breaking Load(KN)
8 16.1 19.7 21.0 22.3 23.7
9 20.3 24.9 26.6 28.3 30.0
9.3 21.7 26.6 28.4 30.2 32.0
10 25.1 30.7 32.8 34.9 37.0
11 30.4 37.2 39.7 42.2 44.8
12 36.1 44.2 47.3 50.3 53.3
12.5 39.2 48.0 51.3 54.5 57.8
13 42.4 51.9 55.5 59.0 62.5
14 49.2 60.2 64.3 68.4 72.5
15.5 60.3 73.8 78.8 83.9 88.9
16 64.3 78.7 84.0 89.4 94.7
17 72.5 88.8 94.8 101 107
18 81.3 99.5 106 113 120
18.5 85.9 105 112 119 127
20 100 123 131 140 148
21.5 116 142 152 161 171
22 121 149 159 169 179
24 145 177 189 201 213
24.5 151 184 197 210 222
26 170 208 222 236 250
28 197 241 257 274 290

Product Structure

  • 6×24-7FC
Specifications
Nominal Diam (mm) Approximate Weight (kg/100m) Nominal Tensile Strength (Mpa)
1470 1570 1670 1770
Min.Breaking Load(KN)
8 20.4 26.3 28.1 29.9 31.7
9 25.8 33.3 35.6 37.9 40.1
10 31.8 41.2 44.0 46.8 49.6
11 45.8 37.2 53.2 56.6 60.0
12 53.7 44.2 63.3 67.3 71.4
13 62.3 51.9 74.3 79.0 83.8
14 81.4 60.2 86.2 91.6 97.1
16 103 78.7 113 120 127
18 127 99.5 142 152 120
20 154 123 176 187 148
22 183 149 213 226 179
24 215 177 253 269 213
26 249 208 297 316 250
28 197 241 345 367 290
30 286 370 396 421 446
32 326 421 450 479 507
34 368 476 508 541 573
36 412 533 570 606 642
38 459 594 635 675 716
40 509 659 703 748 793
