Fiber count		12~72	74~84	86~96	98~108	110~120	122~132	134~144
Max cores in tuber		12	12	12	12	12	12	12
Element number		6	7	8	9	10	11	12
Cable diameter (mm)		5.8	6.2	6.7	7.3	7.8	8.3	8.7
Weight approx. (kg/km)		32	38	46	53	59	66	72
Duct size		Ф10/Ф8	Ф10/Ф8	Ф12/Ф10	Ф12/Ф10	Ф12/Ф10	Ф12/Ф10	Ф12/Ф10
Tensile strength (N)	long term	0.15*G , (G- 1 km cable weight)
	short term	0.5*G , (G- 1 km cable weight)
Crush Resistance (N/100mm)	long term	150
	short term	450
Bending Radius (mm)	Dynamic	≥20×Cable Diameter
	Static	≥10×Cable Diameter
Friction coefficient	Dynamic	0.15
	Static	0.25
Operating Temperature (℃)		20
Minimum blowing length once time		≥1000m within 30minutes
Application		Duct
